1500W BLDC Motor
High-performance 1500W BLDC Golden Motor, delivering efficient power, low noise, and reliable performance for electric bikes, scooters, and light electric vehicles.
Model: BLDC-108
1. Voltages: 48Vdc
2. Rated power: 1.5KW
3. Peak power: 3.0KW
4. Speed: 3200-5000rpm
5. Rated torque: 4 Nm
6. Peak torque: 8 Nm
7. Efficiency: >85%
8. Dimensions: 11x10cm
9. Weight: 4.5kgs
IP Rating: IP54
Drawing(.PDF)
3D Drawing(.STEP)
Performance Report (.xls)
CE-Compliant (EMC Directive)
Certified to:
-
EN IEC 61000-6-4:2019
-
EN IEC 61000-6-2:2019
EMC Emissions – PASSED
-
Radiated emissions compliance from 30 MHz – 1 GHz
Electrostatic Discharge Immunity – PASSED
-
±8 kV Air, ±4 kV Contact
Performance: Criterion B
RF Field Immunity – PASSED
-
80 MHz–6 GHz, 10 V/m
Performance: Criterion A
Magnetic Field Immunity – PASSED
-
30 A/m magnetic stress test
Performance: Criterion A
